Product Overview
We manufacture Italian SAI motor for many years and base on that we develop new product of hydraulic motor. It was tested by Shanghai Hydraulic Research Institute and be certified that combination property of our hydraulic motor is the same level as original hydraulic motor of SAI company Italy.
Characteristics after improving:
1. Eliminate wearing oiliness bearing and adopt hydrostatic equilibrium technology, so it prolongs motor working time and increase more working pressure.
2. Core parts of our motor are produced by pentahedron machining center. It makes very high machining accuracy, increase more than 5% mechanical efficiency and reduce 10% noise.
3. Do evolution on traditional heat treatment technology and use new type of low carbon alloy steel to increase the strength of output shaft of the motor. This can final increase output torque of the motor.
4. We have our own proprietary intellectual property right and include 3 proprietary technologies. Its excellent combination property is obviously much higher than same type products of other Chinese manufacturers. Now our motor has been exported to North American and European market.
Applicable range of products
As GM series hydraulic motor has the above characteristics, it has wide application range. It can be applied in the hydraulic transmission systems of various types of machinery in plastic injection machine, light industry machine, metallurgical equipment, engineering machine, petroleum, coal mine, geological prospecting, railway, ship, environment protection, machine tool and agricultural industries.
Parameters
Type | Displacement (ml/r) | Pressure (Mpa) | Torque (N.m) | Speed (r/min) |
Rated Pressure | Max.Pressure | Rated Torque | Speed Range |
GM05-60 | 59 | 25 | 45 | 235 | 1~700 |
GM05-75 | 74 | 25 | 42.5 | 295 | 1~700 |
GM05-90 | 86 | 25 | 37.5 | 343 | 1~700 |
GM05-110 | 115 | 25 | 40 | 458 | 1~650 |
GM05-130 | 129 | 25 | 37.5 | 513 | 1~650 |
GM05-150 | 151 | 25 | 32.5 | 600 | 1~650 |
GM05-170 | 166 | 25 | 32.5 | 660 | 1~600 |
GM05-200 | 191 | 25 | 28 | 760 | 1~600 |
GM1-100 | 99 | 25 | 42.5 | 385 | 1~550 |
GM1-150 | 154 | 25 | 40 | 600 | 1~550 |
GM1-175 | 172 | 25 | 37.5 | 670 | 1~550 |
GM1-200 | 201 | 25 | 35 | 785 | 1~550 |
GM1-250 | 243 | 25 | 35 | 950 | 1~450 |
GM1-300 | 290 | 25 | 30 | 1130 | 1~350 |
GM1-320 | 314 | 25 | 28 | 1225 | 1~350 |
GM3-425 | 426 | 25 | 42.5 | 1660 | 0.5~500 |
GM3-500 | 486 | 25 | 42.5 | 1895 | 0.5~450 |
GM3-600 | 595 | 25 | 40 | 2320 | 0.5~450 |
GM3-700 | 690 | 25 | 35 | 2700 | 0.5~400 |
GM3-800 | 792 | 25 | 35 | 3100 | 0.5~400 |
GM3-900 | 873 | 25 | 35 | 3400 | 0.5~350 |
GM3-1000 | 987 | 25 | 28 | 3850 | 0.5~300 |
GM5-800 | 807 | 25 | 42.5 | 3150 | 0.3~325 |
GM5-1000 | 1039 | 25 | 42.5 | 4050 | 0.3~300 |
GM5-1200 | 1185 | 25 | 40 | 4625 | 0.3~300 |
GM5-1300 | 1340 | 25 | 40 | 5225 | 0.3~300 |
GM5-1450 | 1462 | 25 | 37.5 | 5700 | 0.3~275 |
GM5-1600 | 1634 | 25 | 37.5 | 6350 | 0.3~250 |
GM5-1800 | 1816 | 25 | 35 | 7075 | 0.3~250 |
GM5-2000 | 2007 | 25 | 35 | 7825 | 0.3~200 |
GM6-1700 | 1690 | 25 | 45 | 6600 | 0.2~250 |
GM6-2100 | 2127 | 25 | 40 | 8300 | 0.2~225 |
GM6-2500 | 2513 | 25 | 35 | 9800 | 0.2~200 |
GM6-3000 | 3041 | 25 | 30 | 11875 | 0.2~175 |
GM05-60,GM05-90,GM05-110,GM05-60,GM05-130,GM05-150,GM05-200
GM1-100,GM1-150,GM1-200,GM1-250,GM1-300,GM1-320
GM2-250,GM2-300,GM2-350,GM2-420,GM2-500,GM2-600,GM2-630,
GM3-350,GM3-425,GM3-500,GM3-600,GM3-700,GM3-800,GM3-1000,
GM4-500,GM4-600,GM4-800,GM4-900,GM4-1000,GM4-1100,GM4-1300,
GM5-1000,GM5-1200,GM5-1300,GM5-1450,GM5-1600,GM5-1800,GM5-2000,
GM6-1700,GM6-2100,GM6-2500,GM6-3000,
L7-2000,L7-2500,L7-3000,L7-3600,L7-4300,L7-4700
L9-5700,L9-6600,L9-7700,L9-8800,L9-10000,L9-12000
